Die Laserfuchs Topseller
Punktmodul, rot, 650nm, 1mW, Klasse 2, Fokus kollimiert, 3-4,5V DC, 15x67mm, Batteriebetrieb The type LFD650-1-4.5(15x68) is a dot laser that projects a red laser dot. The laser module emits light of the wavelength of 650nm. The module contains two button cells that are included. Therefore, wireless operation is possible over several hours. This diode laser module measures 15mm x 68mm. Accordingly, it is a small and effective laser source. Therefore, the module can be used in different applications and also in room light. The optimal operation range of the laser is 10m. This positioning laser is an universal tool for hobby and trade. It reduces the effort that has to be put into positioning and alignment tasks. Typical operation areas are low cost applications. This module is laser class 2. Please note: Caused by the product design deviations between optical axis and mechincal axis are possible. This laser is optimized for room light and projects a bright red laser dot. The visibility can be reduced by bright ambient light or sunlight. Compact size Laser Class 2 Low cost Low power consumption With battery Beam characteristics: elliptical point, point size <4..6mm Axis deviation approx. 1.5 ° to 3 ° Latching switch: Press the switch at the end of the laser module once and the laser is switched on permanently. Pressing it again switches the laser off again. 2 LR44 button cells are included For presentations, positioning or for your cat Delivery Content Im Lieferumfang sind zwei Batterien vom Typ LR44 enthalten. Main Data EAN: 4260129041100 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 1 mW Laser Class: 2 Divergence: H - 1.0 mrad Beam Diameter: 3 mm Size of Laserdot: <4..6mm@5m Operating Distance: 10 m Optics: acryl lense Laser technology: diode Focus: collimated Electrical Parameters Potential of Housing: VDD(+) Operating Voltage: 3 - 4.5 V DC Operating Current: 10 - 30, typ 20 mA Battery: LR44/AG13 alkaline battery, 1.5V Battery count: 2 Mechanical Parameters Size: Ø15x67 mm Material: aluminium Output Aperture: 3 mm Housing Color: black Weight: 27 g Shop+Web Delivery Content: Im Lieferumfang sind zwei Batterien vom Typ LR44 enthalten. Holosun BKA exception: no Accessesories Magnetic Mount for Lasermodul 15mm15mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 15mm Magnetic Mount for Lasermodul 15mmØ15mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 15mm Mount for Lasermodul 15mmØ15mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 15mm certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO Product Safety Information Manufacturer Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.de Responsible Economic Operator Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.deBuy LFD650-1-4.5(15x67) on Amazon
Punktlaser, rot, 650nm, 1mW, Laser Klasse 2, Fokus kollimiert, 3V DC, 6x17mm The type is a dot laser that projects a laser dot. The laser module emits light of the wavelength . This diode laser module measures x . Accordingly, it is a small and effective laser source. The optimal operation range of the laser is .You may use our battery pack with 2 x 1.5 volt batteries as power supply. This dot laser can be applied e.g. in laser levels, laser marking systems, robotics, and laser entertainment area. This module is laser class . The working life of the laser module exceeds . Operating Voltage 3 V DC Laser Class 2 Low power consumption Compact size Low cost Abstrahlcharakteristik: elliptischer Punkt, Punktgröße <8mm@10m Optische Leistung: 1mW (Laserklasse 2); Fokus kollimiert sehr kompakte Bauform: 6x17mm; Achsabweichung: bis zu 3,0° Für Anwendungen in z.B. Laserwasserwaagen, Lasermarkierungssystemen, der Robotertechnik, in Industrie, Handwerk, Hobby und dem Showbereich. Spannungsversorgung 3V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V oder das Netzteil Picotronic LFNT-3 verwenden. Main Data EAN: 4260129044736 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 1 mW Laser Class: 2 Divergence: H - 1.0 mrad Beam Diameter: 3 mm Size of Laserdot: <8mm@10m Operating Distance: 10 m Optics: acryl lense Laser technology: Single Mode Diode Focus: collimated Electrical Parameters Potential of Housing: VDD(+) Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 5 - 15, typ 10 mA Cable color positive: red Cable color ground: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø6x17 mm Material: Brass Cable length: 70 mm Wire type: Belden, Typ 1007, 26AWG Output Aperture: 3 mm Weight: 2 g Holosun BKA exception: no Accessesories Mount for Lasermodul 06mmØ6mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 6mm Magnetic Mount for Lasermodul 6mmØ6mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 6mm Magnetic Mount for Lasermodul 12mmØ6mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 6 mm Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO Product Safety Information Manufacturer Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.de Responsible Economic Operator Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.deBuy LFD650-1-3(6x17) on Amazon
Line laser, red, 650 nm, 5mW, 3-12V DC, Ø9x20 mm, 90 °, Focus fixed (1000mm), Laser class 1 The line laser module LFL650-5-12(9x20)90 is a laser with a wavelength of 650 nm. It stands out for its compact design with dimensions of Ø9x20 mm and offers an impressive lifespan of over 3,000 operating hours. With a fan angle of 90 °, the laser produces a 2-meter long line at a distance of 1 meter. Our power supply unit LFNT-3 is ideally suited for powering it. The line laser has versatile applications: it is used in leveling devices, laser marking systems, and for precise positioning of components. Additionally, it is in demand in industry, crafts, hobby projects, and the show sector. This module belongs to laser class 1. Radiation Pattern: Line, Line Thickness <1.2mm@1m, Optical Output: Laser Class 1; Focus fixed (1000mm); Compact design: Ø9x20 mm; Opening angle: 90 °; Axis deviation: up to 3.0° The opening angle of 90 ° creates a laser line length of 2m at a working distance of 1m. This laser is excellently suited for applications such as component positioning and laser marking systems in industry and crafts. It is operated with a power supply from 3V DC to 12V DC. For optimal power supply, we recommend our power adapter LFNT-3. Main Data EAN: 4260129041001 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Line Optical Power: 5 mW Laser Class: 1 Divergence: H - 1.0 mrad Fan Angle: 90 ° Line Thickness: <1.2mm@1m Operating Distance: 1 m Optics: acryl lense Laser technology: diode Focus: fixed (1000mm) Electrical Parameters Operating Voltage: 3 - 12 V DC Operating Current: 10 - 25, typ 15 mA Cable color positive: red Cable color ground: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø9x20 mm Material: Brass Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 6 mm Weight: 6 g Stripping of wire: 5 mm Holosun BKA exception: no Accessesories Magnetic Mount for Lasermodul 9mm09mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 9mm Magnetic Mount for Lasermodul 12mmØ9mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 9mm Bracket for Lasermodule 9mmØ9mm(25x67) Halterung-Ballhead für Lasermodule mit Durchmesser 9mm Mount for Lasermodul 9mmØ9mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 9mm Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Bracket for Lasermodule 12.5mmØ4-12,5mm(66x69) LASER-MOUNT für Lasermodule mit Durchmesser 4mm bis 12,5mm certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO Product Safety Information Manufacturer Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.de Responsible Economic Operator Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.deBuy LFL650-5-12(9x20)90 on Amazon
cross lasermodule, red, 650nm, 5mW, 45°, class 1, focus 1m, 3-12V DC, 9x20mm The type LFC650-5-12(9x20)45 is a laser that projects a red laser cross. This laser module emits light of the wavelength 650nm. The diode laser module measures 9x20mm. The fan angle of 45° generates a laser cross of 0.8m length at a working distance of 1m. The operating voltage is 3 to 12 volts. This positioning laser is an universal tool for industry, hobby and trade. It reduces the effort that has to be put into positioning and alignment tasks. This module is laser class 1. Beam characteristics: cross, line thickness <1.2mm@1m Optical Power: 5mW (Laser class1); focus 1m Size: 9x20 mm; fan Angle: 45°; axis deviation up to 3° The fan angle of 45° creates a laser line of 0.8m in length at a distance of 1m. For use in, for example, laser marking systems, robot technology and the show area. Operating Voltage: 3-12V DC. For power supply, you can use our Picotronic 3V battery pack or the Picotronic LFNT-3 power pack. Main Data EAN: 4260129041247 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Cross Optical Power: 5 mW Laser Class: 1 Divergence: H - 1.0 mrad Fan Angle: 45 ° Line Thickness: <1.2mm@1m Operating Distance: 1 m Optics: acryl lense Laser technology: diode Focus: fixed (1000mm) Verticality: < ± 1 ° Electrical Parameters Operating Voltage: 3 - 12, typ 3 V DC Operating Current: 10 - 30, typ 20 mA Cable color positive: red Cable color ground: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø9x20 mm Material: Brass Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 6 mm Weight: 6 g Holosun BKA exception: no Accessesories Magnetic Mount for Lasermodul 9mm09mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 9mm Magnetic Mount for Lasermodul 12mmØ9mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 9mm Bracket for Lasermodule 9mmØ9mm(25x67) Halterung-Ballhead für Lasermodule mit Durchmesser 9mm Mount for Lasermodul 9mmØ9mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 9mm Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO Product Safety Information Manufacturer Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.de Responsible Economic Operator Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.deBuy LFC650-5-12(9x20)45 on Amazon
Red point laser, 650 nm, 1mW, 3-12V DC, Ø9x20 mm, Focus collimated, Laser class 2 The type LFD650-1-12(9x20) is a laser for projecting a red laser dot with a wavelength of 650 nm. The laser features a very compact design Ø9x20 mm. The lifespan of the laser module is greater than > 3,000 h. Due to the collimated laser beam, the generated dot size increases slightly with increasing working distance. The power consumption is very low at approximately 25mA. This dot laser is used in, for example, leveling devices, laser marking systems, and for precise positioning of objects. Typical areas of application are low-cost applications. This module falls into the 2. Operating Voltage 3-12V DC Low cost Laser Class 2 Compact size Fixed focus Emission characteristic: elliptical point, point size <4..5mm@5m Optical Performance: Laser Class 2; Focus collimated; Compact design: Ø9x20 mm; Axis deviation: up to 3.0° Dot lasers are frequently used in industrial measurement technology for the precise alignment and positioning of components. This module can be operated with a power supply from 3V DC to 12V DC. For optimal power supply, we recommend our power adapter LFNT-3. Main Data EAN: 4260129041308 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 1 mW Laser Class: 2 Divergence: H - 1.0 mrad Beam Diameter: 3 mm Size of Laserdot: <4..5mm@5m Operating Distance: 10 m Optics: acryl lense Laser technology: diode Focus: collimated Electrical Parameters Operating Voltage: 3 - 12, typ 3 V DC Operating Current: 15 - 30, typ 25 mA Cable color positive: red Cable color ground: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø9x20 mm Material: Brass Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 3 mm Weight: 6 g Holosun BKA exception: no Accessesories Magnetic Mount for Lasermodul 9mm09mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 9mm Magnetic Mount for Lasermodul 12mmØ9mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 9mm Bracket for Lasermodule 9mmØ9mm(25x67) Halterung-Ballhead für Lasermodule mit Durchmesser 9mm Mount for Lasermodul 9mmØ9mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 9mm Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Bracket for Lasermodule 12.5mmØ4-12,5mm(66x69) LASER-MOUNT für Lasermodule mit Durchmesser 4mm bis 12,5mm certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO Product Safety Information Manufacturer Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.de Responsible Economic Operator Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.deBuy LFD650-1-12(9x20) on Amazon
Kreuzlaser, rot, 650nm, 5mW, 45°, Laser Klasse 1, Fokus 1m, 3-4,5V DC, 15x67mm, Batteriebetrieb The type LFC650-5-4.5(15x68)45 is a laser that projects a red laser cross. The focus is optimized for a operation range of 1 meter. The diode has a power of 5mW. Therefore, the module can be used in different applications and also in room light. Using a special optics the laser module produces a sharp cross without using rotating polygon mirrors or motors. This diode laser module is distinguished by its high efficiency and its high lifetime of more than 3000h. This diode laser module measures 15 x 68mm. Accordingly, it is a small and effective laser source. The module contains two button cells that are included. Therefore, wireless operation is possible over several hours. The module is tested in Germany and it is issued with the DIN EN 60825-1:2015-07 certificate. This cross laser can be applied e.g. in leveling, positioning, and marking systems. Additionally it can be used for positioning tasks. The built-in protective lens enables the module to be operated under dusty and harsh industrial environments. Please note: Caused by the product design deviations between optical axis and mechincal axis are possible. This laser is optimized for room light and projects a bright red laser dot. The visibility can be reduced by bright ambient light or sunlight. With battery Laser Class 1 Compact size Operating Voltage 3 V DC Low cost Bright and easy-to-see laser cross for displaying line of sight Laser Class 1: 100% safe handling, safe to use - you can use it without hesitation and without legal requirements. High-quality laser module in a robust metal housing. Compact design incl. 2x LR44 Uniform line width, ideal for positioning and aligning as a tool for hobbyists, craftsmen, construction sites The built-in protective lens allows use of the laser module even in dusty environments and under harsh industrial conditions. Delivery Content Im Lieferumfang sind zwei Batterien vom Typ LR44 enthalten. Main Data EAN: 4260129041957 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Cross Optical Power: 5 mW Laser Class: 1 Divergence: H - 1.0 mrad Fan Angle: 45 ° Line Thickness: <1.2mm@1m Operating Distance: 1 m Optics: acryl lense Laser technology: diode Focus: fixed (1000mm) Verticality: < ± 1 ° Electrical Parameters Potential of Housing: VDD(+) Operating Voltage: 2.7 - 4.5, typ 3 V DC Operating Current: 10 - 30, typ 20 mA Battery: LR44/AG13 alkaline battery, 1.5V Battery count: 2 Mechanical Parameters Size: Ø15x67 mm Material: aluminium Output Aperture: 6 mm Housing Color: black Weight: 25 g Shop+Web Delivery Content: Im Lieferumfang sind zwei Batterien vom Typ LR44 enthalten. Holosun BKA exception: no Accessesories Magnetic Mount for Lasermodul 15mm15mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 15mm Magnetic Mount for Lasermodul 15mmØ15mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 15mm Mount for Lasermodul 15mmØ15mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 15mm certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO Product Safety Information Manufacturer Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.de Responsible Economic Operator Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.de
Punktmodul, rot, 650nm, 1mW, Klasse 2, Fokus kollimiert, 3-4,5V DC, 15x67mm, Batteriebetrieb The type LFD650-1-4.5(15x68) is a dot laser that projects a red laser dot. The laser module emits light of the wavelength of 650nm. The module contains two button cells that are included. Therefore, wireless operation is possible over several hours. This diode laser module measures 15mm x 68mm. Accordingly, it is a small and effective laser source. Therefore, the module can be used in different applications and also in room light. The optimal operation range of the laser is 10m. This positioning laser is an universal tool for hobby and trade. It reduces the effort that has to be put into positioning and alignment tasks. Typical operation areas are low cost applications. This module is laser class 2. Please note: Caused by the product design deviations between optical axis and mechincal axis are possible. This laser is optimized for room light and projects a bright red laser dot. The visibility can be reduced by bright ambient light or sunlight. Compact size Laser Class 2 Low cost Low power consumption With battery Beam characteristics: elliptical point, point size <4..6mm Axis deviation approx. 1.5 ° to 3 ° Latching switch: Press the switch at the end of the laser module once and the laser is switched on permanently. Pressing it again switches the laser off again. 2 LR44 button cells are included For presentations, positioning or for your cat Delivery Content Im Lieferumfang sind zwei Batterien vom Typ LR44 enthalten. Main Data EAN: 4260129041100 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 1 mW Laser Class: 2 Divergence: H - 1.0 mrad Beam Diameter: 3 mm Size of Laserdot: <4..6mm@5m Operating Distance: 10 m Optics: acryl lense Laser technology: diode Focus: collimated Electrical Parameters Potential of Housing: VDD(+) Operating Voltage: 3 - 4.5 V DC Operating Current: 10 - 30, typ 20 mA Battery: LR44/AG13 alkaline battery, 1.5V Battery count: 2 Mechanical Parameters Size: Ø15x67 mm Material: aluminium Output Aperture: 3 mm Housing Color: black Weight: 27 g Shop+Web Delivery Content: Im Lieferumfang sind zwei Batterien vom Typ LR44 enthalten. Holosun BKA exception: no Accessesories Magnetic Mount for Lasermodul 15mm15mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 15mm Magnetic Mount for Lasermodul 15mmØ15mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 15mm Mount for Lasermodul 15mmØ15mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 15mm certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO Product Safety Information Manufacturer Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.de Responsible Economic Operator Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.deBuy LFD650-1-4.5(15x67) on Amazon
Punktlaser, rot, 650nm, 1mW, Laser Klasse 2, Fokus kollimiert, 3V DC, 6x17mm The type is a dot laser that projects a laser dot. The laser module emits light of the wavelength . This diode laser module measures x . Accordingly, it is a small and effective laser source. The optimal operation range of the laser is .You may use our battery pack with 2 x 1.5 volt batteries as power supply. This dot laser can be applied e.g. in laser levels, laser marking systems, robotics, and laser entertainment area. This module is laser class . The working life of the laser module exceeds . Operating Voltage 3 V DC Laser Class 2 Low power consumption Compact size Low cost Abstrahlcharakteristik: elliptischer Punkt, Punktgröße <8mm@10m Optische Leistung: 1mW (Laserklasse 2); Fokus kollimiert sehr kompakte Bauform: 6x17mm; Achsabweichung: bis zu 3,0° Für Anwendungen in z.B. Laserwasserwaagen, Lasermarkierungssystemen, der Robotertechnik, in Industrie, Handwerk, Hobby und dem Showbereich. Spannungsversorgung 3V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V oder das Netzteil Picotronic LFNT-3 verwenden. Main Data EAN: 4260129044736 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 1 mW Laser Class: 2 Divergence: H - 1.0 mrad Beam Diameter: 3 mm Size of Laserdot: <8mm@10m Operating Distance: 10 m Optics: acryl lense Laser technology: Single Mode Diode Focus: collimated Electrical Parameters Potential of Housing: VDD(+) Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 5 - 15, typ 10 mA Cable color positive: red Cable color ground: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø6x17 mm Material: Brass Cable length: 70 mm Wire type: Belden, Typ 1007, 26AWG Output Aperture: 3 mm Weight: 2 g Holosun BKA exception: no Accessesories Mount for Lasermodul 06mmØ6mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 6mm Magnetic Mount for Lasermodul 6mmØ6mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 6mm Magnetic Mount for Lasermodul 12mmØ6mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 6 mm Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO Product Safety Information Manufacturer Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.de Responsible Economic Operator Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.deBuy LFD650-1-3(6x17) on Amazon
Line laser, red, 650 nm, 5mW, 3-12V DC, Ø9x20 mm, 90 °, Focus fixed (1000mm), Laser class 1 The line laser module LFL650-5-12(9x20)90 is a laser with a wavelength of 650 nm. It stands out for its compact design with dimensions of Ø9x20 mm and offers an impressive lifespan of over 3,000 operating hours. With a fan angle of 90 °, the laser produces a 2-meter long line at a distance of 1 meter. Our power supply unit LFNT-3 is ideally suited for powering it. The line laser has versatile applications: it is used in leveling devices, laser marking systems, and for precise positioning of components. Additionally, it is in demand in industry, crafts, hobby projects, and the show sector. This module belongs to laser class 1. Radiation Pattern: Line, Line Thickness <1.2mm@1m, Optical Output: Laser Class 1; Focus fixed (1000mm); Compact design: Ø9x20 mm; Opening angle: 90 °; Axis deviation: up to 3.0° The opening angle of 90 ° creates a laser line length of 2m at a working distance of 1m. This laser is excellently suited for applications such as component positioning and laser marking systems in industry and crafts. It is operated with a power supply from 3V DC to 12V DC. For optimal power supply, we recommend our power adapter LFNT-3. Main Data EAN: 4260129041001 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Line Optical Power: 5 mW Laser Class: 1 Divergence: H - 1.0 mrad Fan Angle: 90 ° Line Thickness: <1.2mm@1m Operating Distance: 1 m Optics: acryl lense Laser technology: diode Focus: fixed (1000mm) Electrical Parameters Operating Voltage: 3 - 12 V DC Operating Current: 10 - 25, typ 15 mA Cable color positive: red Cable color ground: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø9x20 mm Material: Brass Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 6 mm Weight: 6 g Stripping of wire: 5 mm Holosun BKA exception: no Accessesories Magnetic Mount for Lasermodul 9mm09mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 9mm Magnetic Mount for Lasermodul 12mmØ9mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 9mm Bracket for Lasermodule 9mmØ9mm(25x67) Halterung-Ballhead für Lasermodule mit Durchmesser 9mm Mount for Lasermodul 9mmØ9mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 9mm Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Bracket for Lasermodule 12.5mmØ4-12,5mm(66x69) LASER-MOUNT für Lasermodule mit Durchmesser 4mm bis 12,5mm certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO Product Safety Information Manufacturer Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.de Responsible Economic Operator Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.deBuy LFL650-5-12(9x20)90 on Amazon
cross lasermodule, red, 650nm, 5mW, 45°, class 1, focus 1m, 3-12V DC, 9x20mm The type LFC650-5-12(9x20)45 is a laser that projects a red laser cross. This laser module emits light of the wavelength 650nm. The diode laser module measures 9x20mm. The fan angle of 45° generates a laser cross of 0.8m length at a working distance of 1m. The operating voltage is 3 to 12 volts. This positioning laser is an universal tool for industry, hobby and trade. It reduces the effort that has to be put into positioning and alignment tasks. This module is laser class 1. Beam characteristics: cross, line thickness <1.2mm@1m Optical Power: 5mW (Laser class1); focus 1m Size: 9x20 mm; fan Angle: 45°; axis deviation up to 3° The fan angle of 45° creates a laser line of 0.8m in length at a distance of 1m. For use in, for example, laser marking systems, robot technology and the show area. Operating Voltage: 3-12V DC. For power supply, you can use our Picotronic 3V battery pack or the Picotronic LFNT-3 power pack. Main Data EAN: 4260129041247 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Cross Optical Power: 5 mW Laser Class: 1 Divergence: H - 1.0 mrad Fan Angle: 45 ° Line Thickness: <1.2mm@1m Operating Distance: 1 m Optics: acryl lense Laser technology: diode Focus: fixed (1000mm) Verticality: < ± 1 ° Electrical Parameters Operating Voltage: 3 - 12, typ 3 V DC Operating Current: 10 - 30, typ 20 mA Cable color positive: red Cable color ground: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø9x20 mm Material: Brass Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 6 mm Weight: 6 g Holosun BKA exception: no Accessesories Magnetic Mount for Lasermodul 9mm09mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 9mm Magnetic Mount for Lasermodul 12mmØ9mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 9mm Bracket for Lasermodule 9mmØ9mm(25x67) Halterung-Ballhead für Lasermodule mit Durchmesser 9mm Mount for Lasermodul 9mmØ9mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 9mm Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO Product Safety Information Manufacturer Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.de Responsible Economic Operator Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.deBuy LFC650-5-12(9x20)45 on Amazon
Red point laser, 650 nm, 1mW, 3-12V DC, Ø9x20 mm, Focus collimated, Laser class 2 The type LFD650-1-12(9x20) is a laser for projecting a red laser dot with a wavelength of 650 nm. The laser features a very compact design Ø9x20 mm. The lifespan of the laser module is greater than > 3,000 h. Due to the collimated laser beam, the generated dot size increases slightly with increasing working distance. The power consumption is very low at approximately 25mA. This dot laser is used in, for example, leveling devices, laser marking systems, and for precise positioning of objects. Typical areas of application are low-cost applications. This module falls into the 2. Operating Voltage 3-12V DC Low cost Laser Class 2 Compact size Fixed focus Emission characteristic: elliptical point, point size <4..5mm@5m Optical Performance: Laser Class 2; Focus collimated; Compact design: Ø9x20 mm; Axis deviation: up to 3.0° Dot lasers are frequently used in industrial measurement technology for the precise alignment and positioning of components. This module can be operated with a power supply from 3V DC to 12V DC. For optimal power supply, we recommend our power adapter LFNT-3. Main Data EAN: 4260129041308 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 1 mW Laser Class: 2 Divergence: H - 1.0 mrad Beam Diameter: 3 mm Size of Laserdot: <4..5mm@5m Operating Distance: 10 m Optics: acryl lense Laser technology: diode Focus: collimated Electrical Parameters Operating Voltage: 3 - 12, typ 3 V DC Operating Current: 15 - 30, typ 25 mA Cable color positive: red Cable color ground: black Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max. Mechanical Parameters Size: Ø9x20 mm Material: Brass Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 3 mm Weight: 6 g Holosun BKA exception: no Accessesories Magnetic Mount for Lasermodul 9mm09mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 9mm Magnetic Mount for Lasermodul 12mmØ9mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 9mm Bracket for Lasermodule 9mmØ9mm(25x67) Halterung-Ballhead für Lasermodule mit Durchmesser 9mm Mount for Lasermodul 9mmØ9mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 9mm Power supply 3V DC (1200mA)Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC Bracket for Lasermodule 12.5mmØ4-12,5mm(66x69) LASER-MOUNT für Lasermodule mit Durchmesser 4mm bis 12,5mm certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO Product Safety Information Manufacturer Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.de Responsible Economic Operator Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.deBuy LFD650-1-12(9x20) on Amazon
Kreuzlaser, rot, 650nm, 5mW, 45°, Laser Klasse 1, Fokus 1m, 3-4,5V DC, 15x67mm, Batteriebetrieb The type LFC650-5-4.5(15x68)45 is a laser that projects a red laser cross. The focus is optimized for a operation range of 1 meter. The diode has a power of 5mW. Therefore, the module can be used in different applications and also in room light. Using a special optics the laser module produces a sharp cross without using rotating polygon mirrors or motors. This diode laser module is distinguished by its high efficiency and its high lifetime of more than 3000h. This diode laser module measures 15 x 68mm. Accordingly, it is a small and effective laser source. The module contains two button cells that are included. Therefore, wireless operation is possible over several hours. The module is tested in Germany and it is issued with the DIN EN 60825-1:2015-07 certificate. This cross laser can be applied e.g. in leveling, positioning, and marking systems. Additionally it can be used for positioning tasks. The built-in protective lens enables the module to be operated under dusty and harsh industrial environments. Please note: Caused by the product design deviations between optical axis and mechincal axis are possible. This laser is optimized for room light and projects a bright red laser dot. The visibility can be reduced by bright ambient light or sunlight. With battery Laser Class 1 Compact size Operating Voltage 3 V DC Low cost Bright and easy-to-see laser cross for displaying line of sight Laser Class 1: 100% safe handling, safe to use - you can use it without hesitation and without legal requirements. High-quality laser module in a robust metal housing. Compact design incl. 2x LR44 Uniform line width, ideal for positioning and aligning as a tool for hobbyists, craftsmen, construction sites The built-in protective lens allows use of the laser module even in dusty environments and under harsh industrial conditions. Delivery Content Im Lieferumfang sind zwei Batterien vom Typ LR44 enthalten. Main Data EAN: 4260129041957 Warranty: 1 years Customs tariff number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Cross Optical Power: 5 mW Laser Class: 1 Divergence: H - 1.0 mrad Fan Angle: 45 ° Line Thickness: <1.2mm@1m Operating Distance: 1 m Optics: acryl lense Laser technology: diode Focus: fixed (1000mm) Verticality: < ± 1 ° Electrical Parameters Potential of Housing: VDD(+) Operating Voltage: 2.7 - 4.5, typ 3 V DC Operating Current: 10 - 30, typ 20 mA Battery: LR44/AG13 alkaline battery, 1.5V Battery count: 2 Mechanical Parameters Size: Ø15x67 mm Material: aluminium Output Aperture: 6 mm Housing Color: black Weight: 25 g Shop+Web Delivery Content: Im Lieferumfang sind zwei Batterien vom Typ LR44 enthalten. Holosun BKA exception: no Accessesories Magnetic Mount for Lasermodul 15mm15mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 15mm Magnetic Mount for Lasermodul 15mmØ15mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 15mm Mount for Lasermodul 15mmØ15mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 15mm certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO Product Safety Information Manufacturer Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.de Responsible Economic Operator Picotronic GmbH Rudolf-Diesel-Str.2a 56070 Koblenz Deutschland info@picotronic.de
Unser Service für Euch: Bis 13.00 Uhr bestellt – der Laser wird heute noch versendet!
LASERKAUF FÜR SCHLAUE FÜCHSE
Bei Laserfuchs kannst Du erstklassige Laser günstig kaufen und musst dabei keine Abstriche in der Qualität machen. Du fragst dich, wo der Haken dabei ist? Es gibt keinen! Die Lasermodule kannst Du bei uns so günstig kaufen, da wir keine teure Werbung schalten, eine ausgeklügelte Lagerhaltung haben und uns auf dem Lasermarkt einfach sehr gut auskennen. Zudem produzieren wir in großen Mengen und können unsere Rabatte daher direkt an Dich weitergeben.
Du suchst Punktlaser, Linienlaser, Kreuzlaser, DOE-Laser oder Infrarotlaser? Oder interessierst Du dich für Tabletop-Laser oder Laser für 3D Scans? Dann entdecke hier in unserem Laserfuchs Onlineshop unsere ISO-zertifizierten Lasermodule zu günstigen Preisen und hervorragender Qualität.
Laserfuchs wünscht Dir viel Spaß bei der Schnäppchenjagd!
HIER ERFÄHRST DU ALLES, WAS DU WISSEN MUSST!
Ob Bestellmöglichkeiten, Lieferbedingungen oder regelmäßig gestellte Fragen – hier findest Du die passenden Antworten!
Warum sind eure Laser so günstig?
Unsere Laser sind zwar günstig, aber trotzdem hochwertig. Unser gutes Preis-/ Leistungsverhältnis können wir Euch nur durch die hohen Stückzahlen im Einkauf gewährleisten. Diesen Preisvorteil geben wir 1:1 an Euch weiter.
Sind eure Laser sicher?
Wir klassifizieren alle Lasermodule nach der DIN EN 60825-1:2015-07 und liefern euch mit den Modulen Sicherheitempfehlungen in Form eines Merkblattes. Kein Laser verlässt ungeprüft unseren Fuchsbau, jeder Laser hat eine eindeutige Seriennummer und einen Barcode auf dem Sicherheitsschild (Warnschild). Steckerfertige oder batteriebetriebene Laserfuchs-Module sind CE-zertifiziert, alle unsere Produkte sind ordnungsgemäß gekennzeichnet.
Habt ihr auch noch andere Lasermodule?
Laserfuchs ist eine Marke der Picotronic GmbH. Unsere Mutterfirma hat die europaweit größte Auswahl an Lasermodulen! Außerdem kann Picotronic speziell Stückzahlen sind problemlos möglich. Beispiel gefällig? 10.000 Stück schaffen wir locker in 4 Wochen. Solltest Du hier nicht fündig werden, ruf uns einfach an – wir helfen dir gerne weiter!
