Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…

Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…
Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…

€21.90*

Prices incl. VAT. No shipping costs for orders over 100 Euro in the EU

Available, delivery time: 1-2 days

Product number: 70104103
Product information "Dot laser, red, 635 nm, 1 mW, 3 V DC, Ø12x30.5 mm, Laser Class 2, Focus adjustable, Cable length 90…"

Fokussierbarer Punktlaser, rot, 635nm, 1mW, Laser Klasse 2, Fokus einstellbar, 3V DC, 12x30.5mm

The type is a dot laser that projects a red laser dot. This type of laser module with its wavelength of 635nm has an enhanced visibility over a comparable laser with 650nm wavelength. The optical diode power of the laser module amounts to . Typical operation areas are low cost applications. This laser has a very compact design ( x ).Caused by laser classification , no TÜV-registration is necessary. The laser can be applied e.g. in discotheque events and it can be mounted in tools without any problems. (The laser protective measures are still to be considered.)The power consumption of is really low. Accordingly, two batteries can be used for operation and the laser module can be used mobile.

  • Laser Class 2
  • Operating Voltage 3V DC
  • Adjustable focus
  • Compact size
  • Low cost
  • Abstrahlcharakteristik: elliptischer Punkt, Punktgröße veränderbar; Laser mit 635nm besitzen eine bessere Sichtbarkeit als z.B. Laser mit 650nm.
  • Optische Leistung: 1mW (Laserklasse 2); Fokus einstellbar
  • Kompakte Bauform: 12x30.5mm; Achsabweichung: bis zu 3,0°
  • Für Anwendungen in z.B. Laserwasserwaagen, Lasermarkierungssystemen, der Robotertechnik, in Industrie, Handwerk, Hobby und dem Showbereich.
  • Spannungsversorgung 3V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V oder das Netzteil Picotronic LFNT-3 verwenden.

Accessesories

MULTI-MOUNT-12(45x75)-MAGNETIC
Magnetic Mount for Lasermodul 12mm MULTI-MOUNT-12(45x75)
Mount for Lasermodul 12mm Mount-12(20x57)
Mount for Lasermodul 12mm BALLHEAD-MOUNT-12(25x70)
Bracket for Lasermodule 12mm PICO-LPG-635-660
certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development BALLHEAD-MOUNT-12-EP-70117875
Bracket for Lasermodule 12mm KS-MOUNT-12(36X62)-MAGNETIC
Magnetic Mount for Lasermodul 12mm

Main Data

  • EAN: 4260129041216
  • Warranty: 1 years
  • customs tarif number: 90132000000

Technical Parameters

  • Lifetime: > 3,000 h
  • Operating Temperature: -20°C - 40 °C
  • Storage Temperature: -40°C - 80 °C

Optical Parameters

  • Beam Shape: Dot
  • Optical Power: 1 mW
  • Laser Class: 2
  • Divergence: H - 1.0 mrad
  • Size of Laserdot: adjustable
  • Operating Distance: 10 m
  • Optics: acryl lense
  • Laser technology: diode
  • Focus: adjustable

Electrical Parameters

  • Potential of Housing: VDD(+)
  • Operating Voltage: 2.7 - 3.3, typ 3 V DC
  • Operating Current: 30 mA
  • Cable color positive: red
  • Cable color GND: black

Mechanical Parameters

  • Size: Ø12x30.5 mm
  • Material: Brass
  • Cable length: 90 mm
  • Wire type: 26AWG, 0,14mm²
  • Output Aperture: 4 mm
  • Weight: 18.6 g
