UNSERE INFRAROTLASER
FÜR UNSICHTBARE SPARFÜCHSE
Infrarote Wellenlängen liegen zwischen 780nm und 1mm und sind somit für das menschliche Auge unsichtbar. Dennoch – oder gerade deshalb – werden unsere günstigen Infrarotlaser zum Beispiel für Überwachungsaufgaben genutzt, die unbemerkt bleiben sollen, aber auch für Lichtschranken, Datenübertragungen oder zum Einsatz als Zielpointer bei Nachtsichtgeräten. Unsere günstigen Infrarotlaser eignen sich ebenfalls hervorragend für 3D Scans, denn durch ein sogenanntes „random pattern“, zu Deutsch „zufälliges Muster“, können Infrarotlaser das Volumen eines Objekts berechnen, in dem die Positionen der Bildpunkte aus zwei unterschiedlichen Perspektive bestimmt werden.
Laser Lasermodul Punktlaser infrarot 780nm 1mW 3VDC Messinggehäuse 8x23mm
€21.90*
Punktlaser, Infrarot, 780nm, 1mW, Laser Klasse 3R, Fokus kollimiert, 3V DC, 8x23mm
The type is a infrared laser module of the wavelength that projects a red laser line. The laser module has fixed optics and can be used in light barriers, grade and slope control, or pointer applications. The optical diode power of the laser module amounts to . The temperature range of to enables the employment in many applications. The length of the power supply cords amounts to . The power consumption of is really low. Accordingly, two batteries can be used for operation and the laser module can be used mobile. The laser module of the type has a fixed optics. It can be used for light barriers, infrared positioning, data transmission, targeting pointer for night-vision devices, and surveillance tasks. Typical operational areas are surveillance tasks that may be unnoticed. This module is laser class .
Operating Voltage 3 V DC
Laser Class 3R
Fixed focus
Compact size
Low cost
Abstrahlcharakteristik: elliptischer Punkt, Punktgröße <4..6mm@5m; Das Lasermodul liegt mit 780nm im Infrarotbereich.
Optische Leistung: 1mW (Laserklasse 3R); Fokus kollimiert
Sehr Kompakte Bauform: 8x23mm; Achsabweichung: bis zu 3,0°
Für Anwendungen in z.B. Lichtschranken, der Datenübertragung, Infrarot-Positionieraufgaben, Nivelliereinrichtungen oder als Laserpointer im Jagd- oder Überwachungsbereich.
Spannungsversorgung 3V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V oder das Netzteil Picotronic LFNT-3 verwenden.
Accessesories
LF-BRACKET08Bracket for Lasermodule 8mm
MULTI-MOUNT-08(45x75)-MAGNETICMagnetic Mount for Lasermodul 12mm
MULTI-MOUNT-08(45x75)Mount for Lasermodul 08mm
BALLHEAD-MOUNT-08(25x66)Bracket for Lasermodule 8mm
LFNT-3Power supply 3V DC (1200mA)
PICO-LPG-780-1064certified Laser Safety Eyewear PICO-LPG-780-1064 according to DIN EN 207, suitable for infrared wavelengths >765 - 1100 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications
Main Data
EAN: 4260129041278
Warranty: 1 years
customs tarif number: 90132000000
Technical Parameters
Lifetime: > 3,000 h
Operating Temperature: -20°C - 40 °C
Storage Temperature: -40°C - 80 °C
Optical Parameters
Beam Shape: Dot
Optical Power: 1 mW
Laser Class: 3R
Divergence: G - 0.8 mrad
Size of Laserdot: <4..6mm@5m
Operating Distance: 10 m
Optics: acryl lense
Laser technology: diode
Focus: collimated
Electrical Parameters
Potential of Housing: VDD(+)
Operating Voltage: 2.3 - 3.3, typ 3 V DC
Operating Current: 10 - 30, typ 20 mA
Cable color positive: red
Cable color GND: white
Power Supply: LFNT-3
Mechanical Parameters
Size: Ø8x23 mm
Material: Brass
Cable length: 100 mm
Wire type: 26AWG, 0,14mm²
Output Aperture: 3.8 mm
Weight: 4 g
Laser Lasermodul Punktlaser infrarot 780nm 5mW 3VDC 8x23mm
€29.90*
Punktlaser, Infrarot, 780nm, 5mW, Laser Klasse 3R, Fokus kollimiert, 3V DC, 8x23mm
The type is a infrared laser module of the wavelength that projects a red laser line. The laser module has fixed optics and can be used in light barriers, grade and slope control, or pointer applications. The optical diode power of the laser module amounts to . The temperature range of to enables the employment in many applications. The length of the power supply cords amounts to . The power consumption of is really low. Accordingly, two batteries can be used for operation and the laser module can be used mobile. The laser module of the type has a fixed optics. It can be used for light barriers, infrared positioning, data transmission, targeting pointer for night-vision devices, and surveillance tasks. Typical operational areas are surveillance tasks that may be unnoticed. This module is laser class .
Operating Voltage 3 V DC
Low cost
Compact size
Laser Class 3R
Low power consumption
Abstrahlcharakteristik: elliptischer Punkt, Punktgröße <4..6mm@5m; Das Lasermodul liegt mit 780nm im Infrarotbereich.
Optische Leistung: 5mW (Laserklasse 3R); Fokus kollimiert
Sehr Kompakte Bauform: 8x23mm; Achsabweichung: bis zu 3,0°
Für Anwendungen in z.B. Lichtschranken, der Datenübertragung, Infrarot-Positionieraufgaben, Nivelliereinrichtungen oder als Laserpointer im Jagd- oder Überwachungsbereich.
Spannungsversorgung 3V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V oder das Netzteil Picotronic LFNT-3 verwenden.
Accessesories
LF-BRACKET08Bracket for Lasermodule 8mm
MULTI-MOUNT-08(45x75)-MAGNETICMagnetic Mount for Lasermodul 12mm
MULTI-MOUNT-08(45x75)Mount for Lasermodul 08mm
BALLHEAD-MOUNT-08(25x66)Bracket for Lasermodule 8mm
LFNT-3Power supply 3V DC (1200mA)
PICO-LPG-780-1064certified Laser Safety Eyewear PICO-LPG-780-1064 according to DIN EN 207, suitable for infrared wavelengths >765 - 1100 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications
Main Data
EAN: 4260129041223
Warranty: 1 years
customs tarif number: 90132000000
Technical Parameters
Lifetime: > 3,000 h
Operating Temperature: -20°C - 40 °C
Storage Temperature: -40°C - 80 °C
Optical Parameters
Beam Shape: Dot
Optical Power: 5 mW
Laser Class: 3R
Divergence: G - 0.8 mrad
Beam Diameter: 3.5 mm
Size of Laserdot: <4..6mm@5m
Operating Distance: 10 m
Optics: acryl lense
Laser technology: diode
Focus: collimated
Electrical Parameters
Potential of Housing: VDD(+)
Operating Voltage: 2.3 - 3.3, typ 3 V DC
Operating Current: 15 - 55, typ 25 mA
Cable color positive: red
Cable color GND: white
Power Supply: LFNT-3
Mechanical Parameters
Size: Ø8x23 mm
Material: Brass
Cable length: 100 mm
Wire type: 26AWG, 0,14mm²
Output Aperture: 3.5 mm
Weight: 3.5 g
Laserfuchs laser LFT808-200-3(19x22)
€72.90*
Expander lasermodule, infrared, 808nm, 200mW, 3V DC, 19x22mm, class 3B
Operating Voltage 3V DC
Fixed focus
High Power
Laser Class 3B
Compact size
Main Data
EAN: 4260129041056
Warranty: 1 years
customs tarif number: 90132000000
Technical Parameters
Lifetime: > 5,000 h
Operating Temperature: -20°C - 40 °C
Storage Temperature: -40°C - 80 °C
Optical Parameters
Beam Shape: expander
Optical Power: 200 mW
Laser Class: 3B
Fan Angle: 40 °
Size of Laserdot: <100..400mm@0.5m
Operating Distance: 0.5 m
Optics: glass lens AR coated
Laser technology: diode
Protection Lens: no
Focus: fixed (500mm)
Electrical Parameters
Potential of Housing: VDD(+)
Operating Voltage: 2.7 - 3.3, typ 3 V DC
Operating Current: 150 - 450, typ 300 mA
Cable color positive: red
Cable color GND: black
Power Supply: LFNT-3
Mechanical Parameters
Size: Ø19x22 mm
Material: Brass
Cable length: 170 mm
Weight: 29 g
