Laser Lasermodul Punktlaser rot 650nm 0,4mW 3-6VDC Messingehäuse 10x22mm

With these lens you can easily transform a dotlaser into a linelaser.It does not matter which wavelength the laser emit. The dihedral angle of shows a laser line of the length two meters in the distance of one meter. The stable carton offers convincing product protection. The packing was tested for a free-fall of ten meters to protect your lens and ensure undamaged delivery. Main Data EAN: 4260129041339 customs tarif number: 90029000 Optical Parameters Fan Angle: 90 ° Mechanical Parameters Material: Plastic Weight: 0.1 g Buy LFL-LENS90 on Amazon

Punktlaser, rot, 650nm, 0,4mW, Laser Klasse 1, Fokus kollimiert, 3-12V DC, 9x20mm The type LFD650-0.4-12(9x20) is a dot laser that projects a red laser dot. This laser module can be operated without series resistor or control electronics. It can be simply attached to existing power supplies e.g. power supply units of small electrical devices or 12V vehicle power supply networks. The laser module has a controller electronic and just needs to be attached to a power supply. Caused by laser classification 1, no TÜV-registration is necessary. The laser can be applied e.g. in discotheque events and it can be mounted in tools without any problems. (The laser protective measures are still to be considered.)The power consumption of 25mA is really low. Accordingly, two batteries can be used for operation and the laser module can be used mobile. Typical operation areas are low cost applications. The working life of the laser module exceeds 3000h.You may use our battery pack with 2 x 1.5 volt batteries as power supply. Compact size Laser Class 1 Low power consumption Operating Voltage 3-12V DC Low cost Beam shape: dot, elliptical Wavelength: 650 nm optical Power: 0.4mW Laserclass: 1 Warranty: 1 year Accessesories MULTI-MOUNT-09(45x75)-MAGNETICMagnetic Mount for Lasermodul 12mm BALLHEAD-MOUNT-09(25x67)Bracket for Lasermodule 9mm MULTI-MOUNT-09(45x75)Mount for Lasermodul 9mm LFNT-3Power supply 3V DC (1200mA) PICO-LPG-635-660certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4260129041728 Warranty: 1 years customs tarif number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 0.4 mW Laser Class: 1 Divergence: H - 1.0 mrad Beam Diameter: 3 mm Size of Laserdot: <4..5mm@5m Operating Distance: 10 m Optics: acryl lense Laser technology: diode Focus: collimated Electrical Parameters Operating Voltage: 3 - 12, typ 3 V DC Operating Current: 5 - 25, typ 15 mA Cable color positive: red Cable color GND: black Power Supply: LFNT-3 Mechanical Parameters Size: Ø9x20 mm Material: Brass Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 3 mm Weight: 6 g Buy LFD650-0.4-12(9x20) on Amazon

Punktlaser, rot, 650nm, 1mW, Laser Klasse 2, Fokus kollimiert, 3V DC, 6x17mm The type is a dot laser that projects a laser dot. The laser module emits light of the wavelength . This diode laser module measures x . Accordingly, it is a small and effective laser source. The optimal operation range of the laser is .You may use our battery pack with 2 x 1.5 volt batteries as power supply. This dot laser can be applied e.g. in laser levels, laser marking systems, robotics, and laser entertainment area. This module is laser class . The working life of the laser module exceeds . Operating Voltage 3 V DC Laser Class 2 Low power consumption Compact size Low cost Abstrahlcharakteristik: elliptischer Punkt, Punktgröße <8mm@10m Optische Leistung: 1mW (Laserklasse 2); Fokus kollimiert sehr kompakte Bauform: 6x17mm; Achsabweichung: bis zu 3,0° Für Anwendungen in z.B. Laserwasserwaagen, Lasermarkierungssystemen, der Robotertechnik, in Industrie, Handwerk, Hobby und dem Showbereich. Spannungsversorgung 3V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V oder das Netzteil Picotronic LFNT-3 verwenden. Accessesories MULTI-MOUNT-06(45x75)Mount for Lasermodul 06mm MULTI-MOUNT-06(45X75)-MAGNETICMagnetic Mount for Lasermodul 12mm LFNT-3Power supply 3V DC (1200mA) PICO-LPG-635-660certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4260129044736 Warranty: 1 years customs tarif number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 1 mW Laser Class: 2 Divergence: H - 1.0 mrad Beam Diameter: 3 mm Size of Laserdot: <8mm@10m Operating Distance: 10 m Optics: acryl lense Laser technology: Single Mode Diode Focus: collimated Electrical Parameters Potential of Housing: VDD(+) Operating Voltage: 2.7 - 3.3, typ 3 V DC Operating Current: 5 - 15, typ 10 mA Cable color positive: red Cable color GND: black Power Supply: LFNT-3 Mechanical Parameters Size: Ø6x17 mm Material: Brass Cable length: 70 mm Wire type: Belden, Typ 1007, 26AWG Output Aperture: 3 mm Weight: 2 g Buy LFD650-1-3(6x17) on Amazon

With these lens you can easily transform a dotlaser into a linelaser.It does not matter which wavelength the laser emit. The dihedral angle of 90° shows a laser line of the length 0.5m in the distance of one meter. Main Data EAN: 4260129041773 customs tarif number: 90029000 Technical Parameters Operating Temperature: -10°C - 50 °C Storage Temperature: -30°C - 70 °C Optical Parameters Laser Class: 1 Fan Angle: 60 ° Mechanical Parameters Material: Plastic Weight: 0.1 g

Punktlaser, rot, 650nm, 1mW, Laser Klasse 2, Fokus kollimiert, 3-12V DC, 9x20mm The type LFD650-1-12(9x20) is a dot laser that projects a red laser dot. This laser module can be operated without series resistor or control electronics. It can be simply attached to existing power supplies e.g. power supply units of small electrical devices or 12V vehicle power supply networks. The laser module has a controller electronic and just needs to be attached to a power supply. Caused by laser classification 2, no TÜV-registration is necessary. The laser can be applied e.g. in discotheque events and it can be mounted in tools without any problems. (The laser protective measures are still to be considered.)The power consumption of 25mA is really low. Accordingly, two batteries can be used for operation and the laser module can be used mobile. Typical operation areas are low cost applications. The working life of the laser module exceeds 3000h.You may use our battery pack with 2 x 1.5 volt batteries as power supply. Operating Voltage 3-12V DC Low cost Laser Class 2 Compact size Fixed focus Beam shape: dot, elliptical Wavelength: 650 nm optical Power: 1mW Laserclass: 2 Warranty: 1 year Accessesories MULTI-MOUNT-09(45x75)-MAGNETICMagnetic Mount for Lasermodul 12mm BALLHEAD-MOUNT-09(25x67)Bracket for Lasermodule 9mm MULTI-MOUNT-09(45x75)Mount for Lasermodul 9mm LFNT-3Power supply 3V DC (1200mA) PICO-LPG-635-660certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4260129041308 Warranty: 1 years customs tarif number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 40 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 1 mW Laser Class: 2 Divergence: H - 1.0 mrad Beam Diameter: 3 mm Size of Laserdot: <4..5mm@5m Operating Distance: 10 m Optics: acryl lense Laser technology: diode Focus: collimated Electrical Parameters Operating Voltage: 3 - 12, typ 3 V DC Operating Current: 15 - 30, typ 25 mA Cable color positive: red Cable color GND: black Power Supply: LFNT-3 Mechanical Parameters Size: Ø9x20 mm Material: Brass Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 3 mm Weight: 6 g Buy LFD650-1-12(9x20) on Amazon

Fokussierbares DOE-Lasermodul, rot, 650nm, 1mW, Klasse 2, Fokus einstellbar, 3-12V DC, 10x22mm Bei dem Typ DOE-QD650-1-12(10x22)-ADJ handelt es sich um ein Lasermodul, dass für DOE-Anwendungen optimiert ist und eine Wellenlänge von 650nm emittiert. Der Laser verfügt über eine sehr kompakte Bauform (10x22mm). Die Lebensdauer des Lasermoduls ist größer 3.000 Stunden. Die Fokusposition kann stufenlos eingestellt werden. Die Stromaufnahme ist mit ca. 15mA sehr gering, deshalb können problemlos 2 Batterien zur Stromversorgung genutzt und das Lasermodul mobil eingesetzt werden. Als Stromversorgung können Sie z.B unser Battery-Pack mit 2 x 1,5 Volt Batterien (AA) verwenden. Das Lasermodul kann mit zahlreichen DOE's (Ø8x1.2mm) kombiniert werden und findet so vielseitige Anwendungsmöglichkeiten. Dieses Modul fällt, ohne verbautes DOE, in die Laserklasse 2. In Verbindung mit einem DOE kann die Laserklasse abweichen. Abstrahlcharakteristik: Punkt, DOE-optimiert Optische Leistung: 1mW (Laserklasse 2); Fokus einstellbar Kompakte Bauform: 10x22mm; Achsabweichung: bis zu 3,0° In Kombination mit einem entsprechenden Picotronic DOE (Ø8x1.2mm) kann nahezu jede beliebige Struktur erzeugt werden. Im Lieferumfang ist kein DOE enthalten. Spannungsversorgung 3V bis 12V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V oder das Netzteil Picotronic LFNT-3 verwenden. Accessesories MULTI-MOUNT-10(45x75)-MAGNETICMagnetic Mount for Lasermodul 12mm MULTI-MOUNT-10(45x75)Mount for Lasermodul 10mm PICO-LPG-635-660certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development Main Data EAN: 4055132004019 Warranty: 1 years customs tarif number: 90132000000 Technical Parameters Lifetime: > 3,000 h Operating Temperature: -20°C - 50 °C Storage Temperature: -40°C - 80 °C Optical Parameters Beam Shape: Dot Optical Power: 0.75 mW Laser Class: 2 Divergence: H - 1.0 mrad Size of Laserdot: adjustable Operating Distance: 10 m Optics: acryl lense Laser technology: diode Focus: adjustable Electrical Parameters Potential of Housing: VDD(+) Operating Voltage: 2.7 - 12, typ 3 V DC Operating Current: 10 - 25, typ 15 mA Cable color positive: red Cable color GND: black Mechanical Parameters Size: Ø10x22 mm Material: Brass Cable length: 100 mm Wire type: 26AWG, 0,14mm² Output Aperture: 3 mm Weight: 8.5 g Buy DOE-QD650-1-12(10x22)-ADJ on Amazon
