Line laser, blue, 450 nm, 30 °, 16 mW, 3 V DC, Ø14x55 mm, Laser Class 2M, Focus adjustable, Cable l…
€399.90*
Available, delivery time: 1-2 days
Product information "Line laser, blue, 450 nm, 30 °, 16 mW, 3 V DC, Ø14x55 mm, Laser Class 2M, Focus adjustable, Cable l…"
Line lasermodule, blue, 450nm, 16mW, 30°, class 2M, focus adjustable, 3V DC, 14x55mm
The type LC450-16-3-F(14x55)30 is a laser that projects a blue laser line. This laser module emits light of the wavelength 450nm. This diode laser module measures 14x55mm. The fan angle of 30° generates a laser line of 0,5m length at a working distance of 1m. The operating voltage is 3 volts. This positioning laser is an universal tool for industry, hobby and trade. It reduces the effort that has to be put into positioning and alignment tasks. This module is laser class 2M.
- Abstrahlcharakteristik: Linie, Liniendicke kann variiert werden
- Optische Leistung: 16mW (Laserklasse 2M); Fokus einstellbar
- Kompakte Bauform: 14x55mm; Öffnungswinkel: 30°; Achsabweichung: bis zu 3,0°
- Der Öffnungswinkel (30°) erzeugt, bei einem Arbeitsabstand von 1m, eine Laserlinienlänge von 0,53m.
- Für Anwendungen in z.B. Laserwasserwaagen, Lasermarkierungssystemen, der Robotertechnik in Industrie, Handwerk, Hobby und dem Showbereich. Stromversorgung 3V. Zur Stromversorgung können Sie z.B. unser Picotronic Netzteil Picotronic LFNT-3 verwenden.
Accessesories
Magnetic Mount for Lasermodul 14mm
14mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 14mm
Magnetic Mount for Lasermodul 14mm
Ø14mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 14mm
Mount for Lasermodul 14mm
Ø14mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 14mm
Bracket for Lasermodule 14mm
Ø14mm(25x72) Halterung-Ballhead für Lasermodule mit Durchmesser 14mm
Power supply 3V DC (1200mA)
Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC
Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO
certified Laser Safety Eyewear PICO-LPG-405-532 according to DIN EN 207, suitable for blue and green wavelengths >400 - 532 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications
Main Data
- EAN: 4055132005702
- Warranty: 1 years
- Customs tariff number: 90132000000
Technical Parameters
- Lifetime: > 5,000 h
- Operating Temperature: -10°C - 50 °C
- Storage Temperature: -40°C - 70 °C
Optical Parameters
- Beam Shape: Line
- Optical Power: 16 mW
- Laser Class: 2M
- Divergence: C - 0.4 mrad
- Fan Angle: 30 °
- Line Thickness: adjustable
- Operating Distance: 5 m
- Optics: glass lens AR coated
- Laser technology: Single Mode Diode
- Focus: adjustable
Electrical Parameters
- Potential of Housing: isolated
- Operating Voltage: 2.7 - 3.3, typ 3 V DC
- Operating Current: 100 - 210, typ 150 mA
- Cable color positive: red
- Cable color GND: black
- Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max.
Mechanical Parameters
- Size: Ø14x55 mm
- Material: aluminium
- Cable length: 200 mm
- Wire type: Belden, Typ 1007, 26AWG
- Output Aperture: 4 mm
- Housing Color: black
- Weight: 20 g
- Stripping of wire: 5 mm
