Laserfuchs laser LFD650-1-3(6x17)-F2000
€9.90*
Available, delivery time: 1-2 days
Product number:
70151404
Product information "Laserfuchs laser LFD650-1-3(6x17)-F2000"
Punktlaser, rot, 650nm, 1mW, Laser Klasse 2, Fokus 2m, 3V DC, 6x17mm
The type is a dot laser that projects a laser dot. The laser module emits light of the wavelength . This diode laser module measures x . Accordingly, it is a small and effective laser source. The optimal operation range of the laser is .You may use our battery pack with 2 x 1.5 volt batteries as power supply. This dot laser can be applied e.g. in laser levels, laser marking systems, robotics, and laser entertainment area. This module is laser class . The working life of the laser module exceeds .
- Operating Voltage 3 V DC
- Laser Class 2
- Low power consumption
- Compact size
- Low cost
- Abstrahlcharakteristik: elliptischer Punkt, Punktgröße <1.5mm@2m
- Optische Leistung: 1mW (Laserklasse 2); Fokus 2m
- Sehr kompakte Bauform: 6x17mm; Achsabweichung: bis zu 3,0°
- Für Anwendungen in z.B. Laserwasserwaagen, Lasermarkierungssystemen, der Robotertechnik, in Industrie, Handwerk, Hobby und dem Showbereich.
- Spannungsversorgung 3V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V oder das Netzteil Picotronic LFNT-3 verwenden.
Main Data
- EAN: 4055132019662
- Warranty: 1 years
- customs tarif number: 90132000000
Technical Parameters
- Lifetime: > 3,000 h
- Operating Temperature: -20°C - 40 °C
- Storage Temperature: -40°C - 80 °C
Optical Parameters
- Beam Shape: Dot
- Optical Power: 1 mW
- Laser Class: 2
- Divergence: H - 1.0 mrad
- Beam Diameter: 3 mm
- Size of Laserdot: <1.5mm@2m
- Operating Distance: 5 m
- Optics: acryl lense
- Laser technology: Single Mode Diode
- Focus: fixed (2000mm)
Electrical Parameters
- Potential of Housing: VDD(+)
- Operating Voltage: 2.7 - 3.3, typ 3 V DC
- Operating Current: 5 - 15, typ 10 mA
- Cable color positive: red
- Cable color GND: black
- Power Supply: LFNT-3
Mechanical Parameters
- Size: Ø6x17 mm
- Material: Brass
- Cable length: 70 mm
- Wire type: Belden, Typ 1007, 26AWG
- Output Aperture: 3 mm
- Weight: 2 g
