LASERFUCHS line laser, red, 650 nm, , 5 V DC, Ø12x45 mm, 90 °, focus fixed (250mm), laser class 1, incl. power supply

€67.90

Available, delivery time: 1-2 days

Product number: 70106312

Product information "LASERFUCHS line laser, red, 650 nm, , 5 V DC, Ø12x45 mm, 90 °, focus fixed (250mm), laser class 1, incl. power supply"

Line laser, red, 650 nm, , 5 V DC, Ø12x45 mm, 90 °, Focus fixed (250mm), Laser class 1, incl. power supply

The line laser module LFL650-5(12x45)90-F250-NT is a laser with a wavelength of 650 nm. It stands out due to its compact design with dimensions of Ø12x45 mm and offers an impressive lifespan of over 3,000 operating hours. With a fan angle of 90 °, the laser produces a 0.5-meter-long line at a distance of 0.25 meters. The laser module is delivered complete with a power supply. The line laser is versatile in use: it is applied in leveling devices, laser marking systems, and for precise positioning of components. Additionally, it is in demand in industry, craftsmanship, and hobby projects. This module belongs to laser class 1.

Radiation pattern: Line, Line thickness <1mm@0.25m
Optical Power: Laser Class 1; Focus fixed (250mm)
Compact design: Ø12x45 mm; Opening angle: 90 °; Axis deviation: up to 3.0°; DC hollow plug 2.1mm (GND inside)
The opening angle 90 ° generates a laser line length of 0.5m at a working distance of 0.25m.
This laser is excellent for applications such as component positioning and laser marking systems in industry and crafts. It operates with a power supply of 5 V DC. The included power supply is separable from the laser module.

Delivery Content

Including a Picotronic power supply unit LFNT-5-C.

Main Data

EAN: 4260129042008
Warranty: 1 years
Customs tariff number: 90132000000

Technical Parameters

Lifetime: > 3,000 h
Operating Temperature: -20°C - 40 °C
Storage Temperature: -40°C - 80 °C

Optical Parameters

Beam Shape: Line
Optical Power: 5 mW
Laser Class: 1
Divergence: H - 1.0 mrad
Fan Angle: 90 °
Line Thickness: <1mm@0.25m
Optics: acryl lense
Laser technology: diode
Focus: fixed (250mm)

Electrical Parameters

Potential of Housing: VDD(+)
Operating Voltage: 5 V DC
Operating Current: 10 - 30, typ 20 mA
Connector: 2.1 mm DC socket (GND inner)

Mechanical Parameters

Size: Ø12x45 mm
Material: aluminium
Cable length: 1,400 mm
Output Aperture: 6 mm
Weight: 82 g
