Diodenlaser Lasermodul Punktlaser rot 650nm 1mW 3VDC Messinggehäuse 8x23mm

Product information "Diodenlaser Lasermodul Punktlaser rot 650nm 1mW 3VDC Messinggehäuse 8x23mm"

Punktlaser, rot, 650nm, 1mW, Laser Klasse 2, Fokus kollimiert, 3V DC, 8x23mm

The type LFD650-1-3(8x23) is a dot laser that projects a red laser dot. Caused by laser classification 2, no TÜV-registration is necessary. The laser can be applied e.g. in discotheque events and it can be mounted in tools without any problems. (The laser protective measures are still to be considered.)The laser module has a controller electronic and just needs to be attached to a power supply. Typical operation areas are low cost applications. The power consumption of 15mA is really low. Accordingly, two batteries can be used for operation and the laser module can be used mobile. The working life of the laser module exceeds 3000h.You may use our battery pack with 2 x 1.5 volt batteries as power supply.

  • Operating Voltage 3 V DC
  • Laser Class 2
  • Fixed focus
  • Low cost
  • Compact size
  • Abstrahlcharakteristik: elliptischer Punkt, Punktgröße <4..6mm@5m
  • Optische Leistung: 1mW (Laserklasse 2); Fokus kollimiert
  • Sehr Kompakte Bauform: 8x23mm; Achsabweichung: bis zu 3,0°
  • Für Anwendungen in z.B. Laserwasserwaagen, Lasermarkierungssystemen, der Robotertechnik, Hobby, Handwerk, der Industrie und dem Showbereich.
  • Spannungsversorgung 3V. Zur Stromversorgung können Sie z.B. unser Picotronic Batteriepack 3V oder das Netzteil Picotronic LFNT-3 verwenden.

Accessesories

Bracket for Lasermodule 8mm
Ø8mm(58x145) LF-Halterung für Lasermodule mit Durchmesser 8mm
Magnetic Mount for Lasermodul 8mm
Ø8mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 8mm
Magnetic Mount for Lasermodul 12mm
Ø8mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 8mm
Mount for Lasermodul 08mm
Ø8mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 8mm
Bracket for Lasermodule 8mm
Ø8mm(25x66) Halterung-Ballhead für Lasermodule mit Durchmesser 8mm
Power supply 3V DC (1200mA)
Netzteil, Ausgang: 3V DC, offene Kabelenden, Betriebsspannung: 100-240V AC
Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO
certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development

Main Data

  • EAN: 4260129041117
  • Warranty: 1 years
  • Customs tariff number: 90132000000

Technical Parameters

  • Lifetime: > 3,000 h
  • Operating Temperature: -20°C - 40 °C
  • Storage Temperature: -40°C - 80 °C

Optical Parameters

  • Beam Shape: Dot
  • Optical Power: 1 mW
  • Laser Class: 2
  • Divergence: G - 0.8 mrad
  • Beam Diameter: 3.5 mm
  • Size of Laserdot: <4..6mm@5m
  • Operating Distance: 10 m
  • Optics: acryl lense
  • Laser technology: diode
  • Focus: collimated

Electrical Parameters

  • Potential of Housing: VDD(+)
  • Operating Voltage: 2.6 - 3.3, typ 3 V DC
  • Operating Current: 10 - 25, typ 15 mA
  • Cable color positive: red
  • Cable color GND: white
  • Power Supply: Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max.

Mechanical Parameters

  • Size: Ø8x23 mm
  • Material: Brass
  • Cable length: 100 mm
  • Wire type: 26AWG, 0,14mm²
  • Output Aperture: 3.5 mm
  • Weight: 3.5 g

Buy LFD650-1-3(8x23) on Amazon
Optische Diodenleistung: 1 mW
