Kreuzlaser, rot, 650nm, 5mW, 45°, Laser Klasse 1, Fokus 1m, 3-4,5V DC, 15x67mm, Batteriebetrieb
The type LFC650-5-4.5(15x68)45 is a laser that projects a red laser cross. The focus is optimized for a operation range of 1 meter. The diode has a power of 5mW.
Therefore, the module can be used in different applications and also in room light. Using a special optics the laser module produces a sharp cross without using rotating polygon mirrors or motors. This diode laser module is distinguished by its high efficiency and its high lifetime of more than 3000h. This diode laser module measures 15 x 68mm. Accordingly, it is a small and effective laser source. The module contains two button cells that are included. Therefore, wireless operation is possible over several hours. The module is tested in Germany and it is issued with the DIN EN 60825-1:2015-07 certificate. This cross laser can be applied e.g. in leveling, positioning, and marking systems. Additionally it can be used for positioning tasks. The built-in protective lens enables the module to be operated under dusty and harsh industrial environments.
Please note: Caused by the product design deviations between optical axis and mechincal axis are possible.
This laser is optimized for room light and projects a bright red laser dot. The visibility can be reduced by bright ambient light or sunlight.
With battery
Laser Class 1
Compact size
Operating Voltage 3 V DC
Low cost
Helles und gut sichtbares Laserkreuz für das Anzeigen von Sichtlinien.
Laser Klasse 1: 100% sichere Handhabung, gefahrenfrei zu verwenden - Sie können ihn bedenkenlos und ohne rechtliche Auflagen anwenden.
Hochwertiges Lasermodul, , im stabilen Metallgehäuse. Kompakte Bauform inkl. 2x LR44
Gleichmässige Linienbreite, ideal zum Positionieren und Ausrichten als Werkzeug für Hobby, Handwerker, Baustellen
Die eingebaute Schutzlinse erlaubt einen Einsatz des Lasermoduls auch bei staubiger Umgebung und unter harten Industriebedingungen.
Delivery Content
Im Lieferumfang sind zwei Batterien vom Typ LR44 enthalten.
Accessesories
Magnetic Mount for Lasermodul 15mm15mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 15mm
Magnetic Mount for Lasermodul 15mmØ15mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 15mm
Mount for Lasermodul 15mmØ15mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 15mm
Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO
certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development
Main Data
EAN: 4260129041957
Warranty: 1 years
Customs tariff number: 90132000000
Technical Parameters
Lifetime: > 3,000 h
Operating Temperature: -20°C - 40 °C
Storage Temperature: -40°C - 80 °C
Optical Parameters
Beam Shape: Cross
Optical Power: 5 mW
Laser Class: 1
Divergence: H - 1.0 mrad
Fan Angle: 45 °
Line Thickness: <1.2mm@1m
Operating Distance: 1 m
Optics: acryl lense
Laser technology: diode
Focus: fixed (1000mm)
Verticality: < ± 1 °
Electrical Parameters
Potential of Housing: VDD(+)
Operating Voltage: 2.7 - 4.5, typ 3 V DC
Operating Current: 10 - 30, typ 20 mA
Battery: LR44/AG13 alkaline battery, 1.5V
Battery count: 2
Mechanical Parameters
Size: Ø15x67 mm
Material: aluminium
Output Aperture: 6 mm
Housing Color: black
Weight: 25 g
Shop+Web
Delivery Content: Im Lieferumfang sind zwei Batterien vom Typ LR44 enthalten.
Product Safety Information
Manufacturer
Picotronic GmbH
Rudolf-Diesel-Str.2a
56070 Koblenz
Deutschland
info@picotronic.de
Responsible Economic Operator
Picotronic GmbH
Rudolf-Diesel-Str.2a
56070 Koblenz
Deutschland
info@picotronic.de
cross lasermodule, red, 650nm, 5mW, 45°, class 1, focus 1m, 3-4.5V DC, 15x67mm, axial parallel, battery powered
The type LFC650-5-4.5(15x68)45-AP is a laser that projects a red laser cross. The focus is optimized for a operation range of 1 meter. The diode has a power of 5mW.
Therefore, the module can be used in different applications and also in room light. Using a special optics the laser module produces a sharp cross without using rotating polygon mirrors or motors. This diode laser module is distinguished by its high efficiency and its high lifetime of more than 3000h. This diode laser module measures 15 x 67mm. Accordingly, it is a small and effective laser source. The module contains two button cells that are included. Therefore, wireless operation is possible over several hours. The module is tested in Germany and it is issued with the DIN EN 60825-1:2015-07 certificate. This cross laser can be applied e.g. in leveling, positioning, and marking systems. Additionally it can be used for positioning tasks. The built-in protective lens enables the module to be operated under dusty and harsh industrial environments.
Please note: Caused by the product design deviations between optical axis and mechincal axis are possible.
This laser is optimized for room light and projects a bright red laser dot. The visibility can be reduced by bright ambient light or sunlight.
Rastender Schalter: Einmal den Schalter am Ende des Lasermoduls drücken und der Laser ist dauerhaft eingeschaltet. Erneutes Betätigen schaltet den Laser wieder aus.
Abstrahlcharakteristik: Kreuz, Liniendicke 1,2mm@1m
Optische Leistung: 5mW (Laserklasse 1); Fokus: 1m
Kompakte Bauform: 15x67mm; Öffnungswinkel: 45°; Achsabweichung: 1°; Orthogonalität 1°; Der Öffnungswinkel (45°) erzeugt, bei einem Arbeitsabstand von 1m, eine Laserlinienlänge von 0,8m.
Zur Positionierung von Gegenständen und Anwendungen in Industrie, Handwerk, Hobby oder dem Showbereich. Im Lieferumfang sind zwei Knopfzellen LR44 enthalten.
Delivery Content
Including 2x LR44
Accessesories
Magnetic Mount for Lasermodul 15mm15mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 15mm
Magnetic Mount for Lasermodul 15mmØ15mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 15mm
Mount for Lasermodul 15mmØ15mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 15mm
Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO
certified Laser Safety Eyewear PICO-LPG-635-660 according to DIN EN 207, suitable for red wavelengths >630 - 700 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications, Research and Development
Main Data
EAN: 4055132018702
Warranty: 1 years
Customs tariff number: 90132000000
Technical Parameters
Lifetime: > 3,000 h
Operating Temperature: -20°C - 40 °C
Storage Temperature: -40°C - 80 °C
Optical Parameters
Beam Shape: Cross
Optical Power: 5 mW
Laser Class: 1
Divergence: H - 1.0 mrad
Fan Angle: 45 °
Line Thickness: <1.2mm@1m
Operating Distance: 1 m
Optics: acryl lense
Laser technology: diode
Focus: fixed (1000mm)
Verticality: < ± 1 °
Electrical Parameters
Potential of Housing: VDD(+)
Operating Voltage: 2.7 - 4.5, typ 3 V DC
Operating Current: 10 - 30, typ 20 mA
Battery: LR44/AG13 alkaline battery, 1.5V
Battery count: 2
Mechanical Parameters
Size: Ø15x67 mm
Material: aluminium
Output Aperture: 6 mm
Housing Color: black
Weight: 25 g
Shop+Web
Delivery Content: Including 2x LR44
Product Safety Information
Manufacturer
Picotronic GmbH
Rudolf-Diesel-Str.2a
56070 Koblenz
Deutschland
info@picotronic.de
Responsible Economic Operator
Picotronic GmbH
Rudolf-Diesel-Str.2a
56070 Koblenz
Deutschland
info@picotronic.de
This green premium line laser is perfect for all tabletop games. The bright and visible laser line visualizes the line of sight clearly - for an exact and fair gameplay.
The new premium line laser XL520-5 is the perfect visual aid for all true tabletop fans and therefore a valuable aid for a fair and exact gameplay. The green laser is packaged in a high-quality, durable metal case and a must have for professional gamers.
Regardless of whether orcs, demons, undead or hobbits are fighting, the green laser line illuminates the entire table perfectly and is also clearly recognizable in bright ambient light. The tabletop laser XL520-5 can be used safely thanks to laser class 1 - you can use it without hesitation and without any legal requirements. Three replacement packs with batteries and the sturdy metal box for safe storage at tournaments, competitions or at home complete the package.
You can also get a classic red dot, line and cross laser from this series.
Accessesories
Magnetic Mount for Lasermodul 19mm19mm(48x86) MAGNETIC-MOUNT-PRO für Lasermodule mit Durchmesser 19mm
Magnetic Mount for Lasermodul 19mmØ19mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 19mm
Mount for Lasermodul 9mmØ19mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 19mm
Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO
Magnetic Mount for Lasermodul 19mmØ19mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 19mm
Main Data
EAN: 4055132012373
Warranty: 1 years
Customs tariff number: 90132000000
Technical Parameters
Lifetime: > 3,000 h
Operating Temperature: -20°C - 50 °C
Storage Temperature: -20°C - 60 °C
Optical Parameters
Beam Shape: Line
Optical Power: 5 mW
Laser Class: 1
Divergence: H - 1.0 mrad
Fan Angle: 90 °
Line Thickness: <1.2mm@1m
Operating Distance: 1 m
Optics: acryl lense
Laser technology: Single Mode Diode
Focus: fixed (1000mm)
Electrical Parameters
Potential of Housing: VDD(+)
Operating Voltage: 3 - 3.7, typ 3 V DC
Operating Current: 50 - 300, typ 100 mA
Battery: CR123A Lithium Battery, 3V 1400mAh
Battery count: 1
Mechanical Parameters
Size: Ø19x86 mm
Material: aluminium
Output Aperture: 6 mm
Weight: 25 g
Product Safety Information
Manufacturer
Picotronic GmbH
Rudolf-Diesel-Str.2a
56070 Koblenz
Deutschland
info@picotronic.de
Responsible Economic Operator
Picotronic GmbH
Rudolf-Diesel-Str.2a
56070 Koblenz
Deutschland
info@picotronic.deBuy XL520-5 on Amazon
Punktlaser, grün, 532nm, 1mW, Laser Klasse 2, Fokus kollimiert, 3V DC, 16x90mm, achsparallel, inkl. Netzteil
Bei dem Typ LFD532-1-3(16x90)-AP-NT handelt es sich um einen grünen Punktlaser mit einer Wellenlänge von 532nm. Dieses Lasermodul zeichnet sich durch seine solide Bauform aus (16x90mm). Die Lebensdauer des Lasermoduls ist größer 3.000 Stunden. Der Strahlrichtungsfehler (Achsabweichung) beträgt kleiner 1,0°. Das beiliegende Netzteil stellt eine stabile und zuverlässige Stromversorgung her. Dieser Punktlaser findet Anwendung in z.B. Nivelliergeräten, Lasermarkierungssystemen und zur genauen Positionierung von Gegenständen. Für Industrie, Handwerk, Hobby und dem Showbereich. Dieses Modul fällt in die Laserklasse 2.
Abstrahlcharakteristik: elliptischer Punkt, Punktgröße <3..5mm@10m
Optische Leistung: 1mW (Laserklasse 2); Fokus: 10m
kompakte Bauform: 16x90mm; Achsabweichung: bis zu 1,0°; DC-Hohlstecker 2.5mm
Für Anwendungen in z.B. Laserwasserwaagen, Lasermarkierungssystemen, der Robotertechnik, Industrie, Handwerk, Hobby und dem Showbereich.
Das im Lieferumfang enthaltene Netzteil, ist trennbar mit dem Lasermodul verbunden.
Delivery Content
Inklusive einem Picotronic Netzteil LFNT-3-C.
Accessesories
Magnetic Mount for Lasermodul 16mm16mm(48x86) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 16mm
Bracket for Lasermodule 16mmØ16mm(25x75) Halterung-Ballhead für Lasermodule mit Durchmesser 16mm
Picotronic Bracket Mount-16(30x65)Ø16mm(30x65) MOUNT für Lasermodule mit Durchmesser 16mm
Magnetic Mount for Lasermodul 16mmØ16mm(45x75) MULTI-MOUNT-MAGNETIC für Lasermodule mit Durchmesser 16mm
Mount for Lasermodul 16mmØ16mm(45x75) MULTI-MOUNT für Lasermodule mit Durchmesser 16mm
Picotronic Stromversorgung LFNT-3-CNetzteil, Ausgang: 3V DC, mit DC-Stecker Ø2,5 mm (GND innen), Betriebsspannung: 100-240V AC
Picotronic accessory PICO-LENS-CLEANING-PEN-MICRO
certified Laser Safety Eyewear PICO-LPG-405-532 according to DIN EN 207, suitable for blue and green wavelengths >400 - 532 nm, comfortable fit over prescription glasses or alone, side-shields for wide field of view, for laserwelding, lasercutting, lasermarking, laserengraving, cosmetic applications
Main Data
EAN: 4055132007270
Warranty: 1 years
Customs tariff number: 90132000000
Technical Parameters
Lifetime: > 3,000 h
Operating Temperature: 15°C - 30 °C
Storage Temperature: -40°C - 80 °C
Optical Parameters
Beam Shape: Dot
Optical Power: 1 mW
Laser Class: 2
Divergence: D - 0.5 mrad
Beam Diameter: 3 mm
Size of Laserdot: <3..5mm@10m
Optics: glass lens AR coated
Beam Mode: TEM00
Laser technology: YVO4+KTP
Stability: +/- 20% @ 15-30°C
Focus: fixed (10.0m)
Warm up time: < 15 min
Electrical Parameters
Potential of Housing: VDD(+)
Operating Voltage: 2.7 - 3.3, typ 3 V DC
Operating Current: 125 - 375, typ 250 mA
Connector: 2.5 mm DC plug (GND pole inner)
Power Supply: Power Supply, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max, Connector 2,5x5,5x9,5mm center negative
Mechanical Parameters
Size: Ø16x90 mm
Material: Brass
Cable length: 1,650 mm
Output Aperture: 3.5 mm
Weight: 100 g
Shop+Web
Delivery Content: Inklusive einem Picotronic Netzteil LFNT-3-C.
Product Safety Information
Manufacturer
Picotronic GmbH
Rudolf-Diesel-Str.2a
56070 Koblenz
Deutschland
info@picotronic.de
Responsible Economic Operator
Picotronic GmbH
Rudolf-Diesel-Str.2a
56070 Koblenz
Deutschland
info@picotronic.deBuy LFD532-1-3(16x90)-AP-NT on Amazon
€179.90*
